Description
For a Parts List and Wiring Diagram Click Here
Two Speed Capability for Maintenance and Light Duty Production Welding and Soldering
- 113/226 CFM high vacuum fume extraction and filter capacity
- Designed for field and bench work, this unit is lightweght, portable, and easy to use
- Unit accomodates 9 different filtering combinations for maximum flexibility in all types of applications
- 73-201-HEPA: HEPA filter for Hexavalent Chromium control
- 73-201-95: 95% efficiency filter included for general welding fume protection
- Built in spark trap for fire safety
- LED filter status light alerts operator to the need for filter change
- Includes 10 foot extraction hose (extra lengths can be added) with flexible nozzle assembly
- Also includes magnetic support base for hands free operation
- May be direct connected to MIG extraction gun with optional adapter
- Optional two-operator adapter increases use and flexibility
- Heavy Duty steel cabinet will withstand rugged daily use
- UL Listed
- Made in USA
- Dimensions: 24″L x 17″H x 12″W
- Weight: 58 pounds (with filters installed)
